Product Description
Mishimoto Performance Intercooler Sleek Silver - 2021+ Ford Raptor
Key Features
- Direct fit for the 2017+ Ford Raptor
- 10°F (5.5°C) reduction in intake air temp
- 77% increase in internal core volume
- 163% increase in external fin surface area
- All-aluminum, TIG-welded construction
- Internal fin design for maximum heat transfer with minimal pressure drop
- Fits with stock and Mishimoto intercooler pipe kits
- Fits with stock intercooler fans without modification
- Available in Sleek Silver or Stealth Black
- Mishimoto Lifetime Warranty
TECH SPECS
| Applications | 2015+ Ford F-150 EcoBoost 2017+ Ford Raptor 3.5L V6 EcoBoost 2018-2019 Ford Expedition 3.5L V6 EcoBoost 2018-2019 Lincoln Navigator 3.5L V6 EcoBoost |
|---|---|
| Engine Codes | 2.7L V6 EcoBoost 3.5L V6 EcoBoost |
| Maximum Recommended Boost Pressure (PSI) | 50 |
| Overall Length (in) | 29 |
| Overall Height (in) | 9.5 |
| Overall Width (in) | 7 |
| Core Type | Bar-and-Plate |
| Core Thickness (in) | 4.72 |
| Core Length (in) | 19.6 |
| Core Height (in) | 9.4 |
| Inlet (in) | 2.5 |
| Outlet (in) | 3 |
| Installation Notes | 27 in-lbs (3NM) recommended for all T-bolt and constant-tension T-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4NM). Do not exceed the maximum torque rating of 35 in-lbs (4NM). |
